Lift Magnets

ERIEZ FLOTATION GROUP CHILE S.A.

Descripción

ERIEZ FLOTATION GROUP CHILE S.A.

ENVIAR EMAIL

EPL-121 650 lbs (295 kg)
EPL-154 4,000 lbs (1814 kg)

SafeHold RPL SeriesIdeal for carrying semi-finished products with flat or round surfaces such as machine parts, press molds for forming, steel plate, bars etc. Permanent magnetic type, requiring no power supply.

RPL-3 300 lbs (135 kg) flat material150 lbs (68 kg) round material
RPL-11 1,100 lbs (500 kg) flat material550 lbs (250 kg) round material

SafeHold XPL SeriesIdeal for carrying semi-finished products with flat or round surfaces such as machine parts, press molds for forming, steel plate, bars, etc. Permanent magnetic type, requiring no power supply.

XPL-4/3 400 lbs (181 kg) flat material300 lbs (136 kg) round material
XPL 8/6 800 lbs (363 kg) flat material600 lbs (272 kg) round material
XPL-15/9 1,500 lbs (680 kg) flat material900 lbs (409 kg) round material
XPL-24/16 2,400 lbs (1,090 kg) flat material1,600 lbs (727 kg) round material

ST SeriesThe STD Series units have a miniaturized rectifier/drop control circuit with a “Lift-Off-Drop" switch attached to the magnet. This eliminates the need for a separate rectifier and can briefly cancel out and residual magnetism to allow the load to be easily discharged from the magnet.

ST-4D 375 lbs (170 kg) flat material
ST-5D 1,030 lbs (468 kg) flat material
ST-8D 2,800 lbs (1,270 kg) flat material

SL-4A Selecto ElectroLightweight, power-packed to provide reliable, fast lifts for hundreds of applications. Easy to install, easy to use. Eliminates hooks, slings or grabs. Lifts up to 375 lbs (170 kg).

Más información sobre este producto consulte en: http://www.eriez.com/Products/Index/Xplift1
