Cathodic Protection Design (DNV-RP-B401 1983)

The Cathodic Protection Design (ANOD) module is used to design a bracelet anode system by helping the engineer to select an appropriate anode size and spacing along the pipeline. Alternatively, the module may be used to quickly check the validity of an existing or proposed design.

The ANOD module calculation method, default values and help screen information, are based primarily on Det Norske Veritas’ recommended practice for cathodic protection design (DNV RP B401, 1993).

  • the critical collapse pressure;
  • the critical buckling curvature and associate bending moment;
  • the hydrostatic pressure acting on the pipeline
  • Pressure Containment (Bursting)
  • Local Buckling (General); which comprise of:
  • Local Buckling External Overpressure only (System Collapse)
  • Propagation Buckling
  • Local Buckling (Combined Loading Criteria). This may be Load or Displacement Controlled.

Más información sobre este producto consulte en: http://www.penspen.com/capabilities/services/software-tools/plusone/modules/installation-contractor-package/
