Wall Thickness & Buckling Bundle
The Bending Buckling module (BUCK) determines the hydrostatic collapse pressure for a pipe having a defined eccentricity using Timoshenko’s elastic stability formula. The module also calculates the critical buckling curvature and moment taking full account of the elastic-plastic behaviour of the pipe material (the material model is defined using a bi-linear description of the elastic and plastic regions).
To operate this module, the user inputs the pipe dimensions and material properties and the water depth/density. BUCK then calculates the following:
- the critical collapse pressure;
- the critical buckling curvature and associate bending moment;
- the hydrostatic pressure acting on the pipeline
Wall Thickness Calculation (DNV OS-F101 2010)
- Pressure Containment (Bursting)
- Local Buckling (General); which comprise of:
- Local Buckling External Overpressure only (System Collapse)
- Propagation Buckling
- Local Buckling (Combined Loading Criteria). This may be Load or Displacement Controlled.
Más información sobre este producto consulte en: http://www.penspen.com/capabilities/services/software-tools/plusone/modules/wall-thickness-buckling-bundle/
