- Ripperveyor cutting head system
- 1473 mm (58 in.) cutter head diameter
- Cooling system designed to meet mine’s water requirements
- Bolted construction to meet shaft entry requirements
- Individual motors with direct-drive transmissions to power the cutter, traction, gathering, and hydraulic systems
- Outboard access for motors, gearcases, controllers and other major components to reduce downtime and maintenance costs
- Remote radio control operations, with different frequencies available for multi-machine sections
- OptiDrive AC electronic system to provide smooth transmission responsiveness
- Faceboss control platform to facilitate an optimal balance of production rate and cost
- Dual scrubber systems for dust control (optional)
| Machine weight | 95 kg | 210,000 lbs. |
| Maximum cutting height | 4,615 mm | 182 in. |
| Minimum cutting height | 2,095 mm | 82 in. |
| Minimum tram height | 1.8 m | 71 in. |
| Conveyor width | 965 mm | 38 in. |
| Cutterhead power @ 2300V 60 Hz | 250 kW | 335 hp |
| Total machine power @ 2300V 60 Hz | 840 kW | 1126 hp |
