SIMOTICS HV Series H-modyn
Consulta información técnica, comercial y disponibilidad de esta solución de Siemens.
Información sobre SIMOTICS HV Series H-modyn | Siemens
ENVIAR EMAIL
Individual drive solutions for application and industry sector-specific customer requirements
General description
The SIMOTICS HV Series H-modyn machines for induction motors, synchronous motors and generators are suitable for use in the whole of the process industry. Either Oil & Gas, Chemical, Steel, Water or Wastewater, Air separation, Pulp & Paper, or others – every branch will find the right machine.
Technical data overview
|
Standard |
Option |
|
|---|---|---|
|
Rated voltage / frequency: |
10 kV / 50 Hz;13.2 kV / 60 Hz |
6 kV / 50 Hz |
|
Type of construction: |
IM B3 (IM 1001) |
|
|
Degree of protection: |
IP55 |
IP56, WP II |
|
Cooling type: |
IC 81 W |
IC 86 W, IC 616 |
|
Shaft height: |
800, 900, 1000, 1120 mm |
|
|
Rated power: |
2 – 38 MW |
|
|
No. of poles: |
2 – 16 |
|
|
Bearings: |
Sleeve bearings,Non locating bearings |
– Locating bearings at the DE- Increased axial play (e.g. for refiners) |
|
Speed: |
constant, variable speed |
|
|
Standards: |
IEC, EN, DIN, VDE |
NEMA, Specifications (e.g. marine, oil & gas) |
|
Explosion-protection: |
EExnAII, EExp |
Features
Más información sobre este producto consulte en: http://www.siemens.com/h-modyn
