IADC Chart

IADC Code Classifications

STEEL TOOTH BITSIADC 1 SERIES DRILL BITSThese bits are used to drill low-compressive strength, soft formations. Long projection tooth lengths are used on high offset cones to provide the greatest penetration rates possible. Wear-resistant hardfacing is used to control tooth wear. On the softest bit types this hardfacing completely covers the bit teeth.

IADC 2 SERIES DRILL BITSThese bits are used to drill high-compressive strength, medium hard formations. Short projection teeth with reduced crest length are used in this series of bit designs. Durable hardfacing is applied to reduce tooth wear.

IADC 3 SERIES DRILL BITSThese bits are used to drill hard and abrasive formations. Very short, closely spaced teeth with minimum amounts of hardfacing are used for breakage resistance. These bits must withstand high loads and drill abrasive formations with a crushing, cutting action.
