Differents plates to cathodes manufacture The ICL´s cathodes are manufactured following precise specifications provided by our clients. In all our stainless steel cathodes, ICL complies with general manufacturing requirements by the industry and stress relieving treatments, suitable for good mechanical behavior.
| MATERIAL THICKNESS AVAILABLE FOR CATHODE |
| Titanium |
2 |
| stainless steel |
2 |
| stainless steel |
3.25 |
| stainless steel |
3.35 |
| STAINLESS STEEL PLATE CATHODE |
| Chemical Composition |
TOLERANCE |
| C To 0.030% |
thickness: +-0.08mm. |
| Cr From 16.00% To 18.50% |
Horizontal Tolerance:+-1.0mm. |
| Mn to 2.00% |
Vertical tolerance:+-1.0mm. |
| Mo from 2.00% to 3.00% |
SUPERFICIAL ENDING |
| Ni from 10.00% to 14.00% |
ASTM a 480 tipo 2B ( 0.10 A 0.60 microns in rugosity |
| P hasta 0.045% |
The plate must be oils-free and surface contamination |
| S from 0.03% |
| S to 1.00% |
BAR-BODY VOLTAGE DROP |
| |
less than 6mv |
