Revolving Clamp for 1-2 Drums – KG-T2
- 360° continuous rotations in both directions
- Strong double T profiles
- Designed to handle the standard steel oil drums
- Arms fitted with interchangeable rubber stripes, to avoid damages to drums
- Check valve with pressure relief and gauge
- Reduced weight, LL and centre of gravity
Technical Data
KG-T2
| KG 06 T2A | 600 | 320 | 460-1560 | 470x240x42x70 | 870 | 690 | 781 | 445 | 179 | 262 | 229 | 341 | 200 | 9 | 2 A |
| KG 10 T2A | 1000 | 320 | 460-1560 | 470x240x42x70 | 870 | 690 | 781 | 455 | 179 | 257 | 231 | 341 | 200 | 9 | 2 A |
E= arm thickness with rubber
T= arm thickness at the base with rubber.
Standard fittings:
Two hydraulic functions required
Power regeneration hydraulic circuit
Special check valve
Arms welded to the guides
On request:
