- Bar type design.
- Pallet handler for handling two or four pallets in depth.
- These models offer the possibility to lift pallets on both sides, either two or four at a time.
- Excellent visibility through the body.
- Separate sideshift provides constant sideshift range regardless of the fork opening.
- Synchronized forks mouvement.
- Bolt-on forks with specially reinforced heel area.
- Forks are hydraulically adjusted with a single lever.
Technical Data
DS-FS two four
DS 10 FS A | 1000 | 1200 | 550 | 550×1930 | 2350x80x50 | 1200 | 980 | 1350 | 719 | 536 | 207 | 2 |
DS 13 FS B | 1300 | 1200 | 550 | 550×1930 | 2350x80x50 | 1200 | 980 | 1350 | 775 | 514 | 207 | 3 |
DS 25 FS B | 2500 | 1200 | 540 | 540×1920 | 2350x80x60 | 1310 | 1100 | 1350 | 987 | 505 | 244 | 3 |
DS 30 FS C | 3000 | 1200 | 540 | 540×2020 | 2350x80x60 | 1410 | 1300 | 1350 | 1030 | 496 | 244 | 4 |
DS 35 FS C | 3500 | 1200 | 560 | 560×1960 | 2350x80x60/90×55 | 1420 | 1500 | 1350 | 1325 | 435 | 292 | 4 |
DS 45 FS C | 4500 | 1200 | 560 | 560×1960 | 2350x80x70/100×60 | 1420 | 1500 | 1350 | 1380 | 460 | 292 | 4 |
DS 56 FS C | 5600 | 1200 | 560 | 560×1960 | 2350x80x75/100×70 | 1420 | 1500 | 1350 | 1520 | 490 | 324 | 4 |
Two hydraulic functions required.
